Washtech M2C – Professional Passthrough Dishwasher With Heat Condensing Unit

The M2C will fit into bench gaps between 595mm and 640mm, and incorporates electronic controls providing soft wash start, the eco power saver system, easy to read temperatures for HACCP reporting, chemical pump adjustments and priming, cycle customisation, immediate fault diagnosis and many other options.

Equipped with a heat condensing unit which enables the same great results as the M2 while running on a cold water supply. This also allows for easier and lower cost water treatment options. The use of the steam to pre-heat the cold inlet water enables the M2C to reduce energy consumption, emissions and ventilation requirements, while also providing a cooler and drier operating environment.

•  Autostart on door closure 1, 2 and 3 minute cycles
• Up to 1080 plates per hour
• Reliable results through robust stainless steel wash and rinse arms with precision stainless jets
• Durable stainless steel construction
• Moffat’s Comprehensive 5-2-1 Warranty (5 Year Cabinet Parts Only / 2 Year Wash Pump Parts & Labour / 1 Year Parts & Labour)
• Heat Recovery Condensor preheats cold water supply and significantly reduces steam emitted
• Suitable for installation without canopy in many situations – with good general dishroom ventilation
• Self cleaning jets located above the condenser flush the unit every time the machine is drained
• Low cold water consumption of 2.4 litres per cycle
• Assured final rinse ensures the correct temperature and pressures every time through it’s rinse pump and 316 stainless break tank
• Double filtration system via scrap trays and separate wash inlet filter
• Soft start ensures great results through progressively pressurising the cycle to provide a consistent and even clean every time
• EcoPower reduces temperatures and energy consumption when machine is not being used
• Electrical Three phase 415V 50Hz 15A/phase
• Maximum Power Consumption Three Phase 10.0kW
• Heating Wash 5.0kW Rinse 9.0kW
• Dimensions W 705mm x D 720mm x H 2035mm

Easy installation supplied complete with:

• Water supply hose
• Dual detergent and rinse aid pumps with injector lines
• Drain pump outlet hose
• Unique 595mm to 640mm bench gap compatibility
• No commissioning required

Includes:
2 x 600 70028 – 500mm dish rack
1 x 600 70029 – 500mm cup rack
2 x C660503 – cutlery container
